Ardoo Caresafe 140 Hoist

The Ardoo CareSafe Hoist is a compact and versatile, small folding hoist designed to lift disabled users in and out of cars and converted vans. Its compact design also makes it the ideal choice of a travel hoist.  The CareSafe hoist can be used indoors and outdoors with ease and is even small enough to be fitted into a car boot. With a one piece construction, this remarkable hoist can be erected or folded in less than 40 seconds, making it the ideal travel partner.  Use it to transfer a person into a car and lift them out into their wheelchair with ease.

The Ardoo Caresafe Hoist can also be converted into a standing transfer hoist for those users who can bear some weight.  The optional sit to stand conversion kit includes a footplate and knee pad.  The kit converts the hoist into a standing hoist thus making it ideal for those users who's transfer needs change in line with their illness. This hoist has been fully tested, is CE complaint and is patented since 09/04/2014. One year warranty on battery and 4 years on all other parts.

Free demonstrations: We offer free demonstrations of the Ardoo hoist in selected areas of the UK and Ireland - just call us on 028 92 633 798 to check if this is possible in your area.

Key features

• Can be used indoors and outdoors
• Can be converted into a standing hoist
• Hoists users in and out of most cars and kango style vans
• Can be folded small enough to be placed in to a car boot
• It can be taken on holiday and stored in the hold of the plane
• Very small footprint, suitable for small spaces and bathrooms
• It can lift a supine person from the floor
• It can be erected and folded in under a minute

Specification

• Safe Working Load 140 kg (22 stone) (308 lbs)
• Assembled Hoist Including Battery 23 kg (3.6 stone) (51 lbs)
• Overall Length 1070mm (42 inch)
• Height when folded 267mm (10.5 inch)
• Maximum Boom Height (boom lifting hooks) 1650mm (65 inch)
• Minimum Boom Height (boom lifting hooks) 1135mm (45 inch)
• Turning Radius 1066mm (42 inch)
• Internal Width(when legs closed) 420mm (17 inch)
• External Width (when legs closed)480mm (19 inch)
• Internal Width (when legs open) 970mm (38 inch)
• External Width (when legs open) 1030mm (40.5 inch)
• Overall Height of Legs 115mm (4.5 inch)
• Height of Wheels 77mm (3 inch)
• Folded Dimensions  1143mm(L) X 482mm (W) X 267mm (H) (45 inch(L) x 19 inch (W) x 10.5 inch (H))
• Hoist Frame Manufactured from Mild Steel
• Electrical Specifications Battery12v re-chargeable sealed lead acid battery
• Capacity 2.0AH 24VDC
• Charger Rated Input…220-240V AC 50Hz – 36 VA
• Charger Rated Output 29V 1.IA
• Environmental Conditions Operating Temperature 5 to 40°C
• Storage Temperature -20° to 60°C
• IP RATINGS 12V rechargeable sealed lead Acid Battery
• Actuator & Controls IPX4
• Actuator Duty Cycles 10% (2min/18min)
• Charger Approx. 4 hours
• Ardoo Caresafe 140 Hoist meets with: IEC60601-2005 3rd edition ANSI/AAMI ES60601:1 2005 3rd edition
